I need a fuctional diagram of the workings of our lasercutter for a presentation. So tried the assistant of nprofile1qy2hwumn8ghj7un9d3shjtnyd968gmewwp6kyqpqdxvu0dljzawytq8y99ace9l7rpsv4dj6q0tmv63yynrwaeyj6eus0nfrjj (nprofile…frjj) (taday totally chilling for them ;-) ), which gave me a really good concept for an educational poster. Including style hints like to make the laser tube glow a bit orange and make the invisible beam visible. Then (after asking) it gave me a prompt for an AI image generator. I chose Googles Nanobanana.

This is the result. It looks nice but if you know anything about a laser cutter or even mechanics you see that this is very fine looking 💩

So I'll fire up #freeCAD for the model and try my very best in #inkscape to make the image.
